23.9 Inch Bar Type LCD Display 1920*359 LVDS 700nits Bar LCD Screen

Shenzhen Rogin Electronics Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 23.9 Inch Bar Type LCD Display 1920*359 LVDS 700nits Bar LCD Screen from wholesalers

    Buy cheap 23.9 Inch Bar Type LCD Display 1920*359 LVDS 700nits Bar LCD Screen from wholesalers
    • Buy cheap 23.9 Inch Bar Type LCD Display 1920*359 LVDS 700nits Bar LCD Screen from wholesalers

    23.9 Inch Bar Type LCD Display 1920*359 LVDS 700nits Bar LCD Screen

    Ask Lasest Price
    Brand Name : ROGIN
    Model Number : LCMA-RX0239TA01-C070
    Price : Price is negotiable.
    Payment Terms : T/T, L/C
    Supply Ability : Spot adequacy
    Delivery Time : 6-8 weeks
    • Product Details
    • Company Profile

    23.9 Inch Bar Type LCD Display 1920*359 LVDS 700nits Bar LCD Screen

    23.9 inch Bar Type LCD Display 1920*359 LVDS 700nits

    Product Advantage ►


    1. 3 set cutting machines, 2 advanced cutting production lines, the longest one can be cut to 1.7m (75 inch cutting).
    2. Advanced cutting technology to ensure the yield and precision.
    3. High reliability with same features as original panel.
    4. High Anti-vibration.
    5. Brightness can be customized (500-2500nit).
    6. Long life time 50K hours(Typ), up to 80K hours.

    Product Application


    1. Commecial signage : Advertising and Price Shelves.
    2. Public transportation: Bill board for Bus/Metro and light rail.
    3. Guidance board, Lift advertising board.
    4. Financial services. Bank call notice board.
    5. Name card.
    6. Advertising board on taxi.

    Specifications

    LCMA-RX0239TA01-C070

    BrandRogin
    SeriesBar Type LCD Display
    Panel Size
    23.9 inch
    Model
    LCMA-RX0239TA01-C070
    Brightness
    700
    Power Consumption
    22W
    Resolution
    1920*359
    Active Area
    597.6*112mm
    Overall Size
    623.5*140*13.57mm
    Viewing Angle
    /
    Interface Definition
    LVDS (2 ch, 8-bit)
    Backlight TypeWLED
    Contrast Ratio
    3000:1
    Aspect Ratio
    16:3
    Touch PanelWithout
    Operating Temperature
    0~50 ℃

    Product catalog of bar type LCD display.pdf
